Scorpion Vision
M12 Lens 12mm F5.6
SKU: SVL-F1256FM
Couldn't load pickup availability
Specification
Specification
Shipping & Returns
Shipping & Returns
Shipping
Free shipping to all UK addresses (subject to a minimum order value of £20).
Standard shipping to all other destinations - select destination on checkout to get pricing.
Taxes may apply to your order depending on the shipping destination. Please note that the customer is responsible for any applicable taxes and duties. Goods are shipped with incoterms DAP.
Returns
If you would like to return or have any questions about your returning your item, please contact returns@scorpion.vision
Key Features
- Focal Length: 12mm
- F Number: F5.6
- Iris: Non-adjustable
- Mount: M12
- Format: 2/3"
- Filter Size: n/a
- Megapixel: 10MP
- Horizontal Field of View: 40 Degrees
- Distortion: <-1.2%
- Back Focus: 8mm
- Working distance: ∞ ~ 0.1m
- Wavelength: 400nm-950nm
Sample Images
In this sample image, the penny (d=20.3mm) was at a distance of 20cm from the lens. The sensor used was a 1/3" Aptina MT9V024.
This lens has a large focal length and minimal distortion.
In these next images, the sensor used was a 1/4" Sony ICX618. The first image is focused at a distance of 38mm from the lens and the second at 55mm. This lens has a medium F Number of F5.6 creating a reasonable depth of field while still allowing a good amount of light to reach the sensor.
