Scorpion Vision
M12 Lens 12mm F2.8
SKU: SVL-IR1228B5M
Couldn't load pickup availability
Specification
Specification
Shipping & Returns
Shipping & Returns
Shipping
Free shipping to all UK addresses (subject to a minimum order value of £20).
Standard shipping to all other destinations - select destination on checkout to get pricing.
Taxes may apply to your order depending on the shipping destination. Please note that the customer is responsible for any applicable taxes and duties. Goods are shipped with incoterms DAP.
Returns
If you would like to return or have any questions about your returning your item, please contact returns@scorpion.vision
Key Features
- Focal Length: 12mm
- F Number: F2.8
- Iris: Non-adjustable
- Mount: M12
- Format: 1/1.8"
- Filter Size: n/a
- Megapixel: 5MP
- Diagonal Field of View: 41 Degrees
- Distortion: <-1.75%
- Back Focus: 8.56
- Working Distance: 0.1m - ∞
- Wavelength: 400nm-900nm
Sample Images
In this sample image, the sensor used was a 1/3" Aptina MT9V024. In this image, the coin was at a distance of approx. 78mm.
In this sample image, the penny (d=20.3mm) was at a distance of 20cm from the lens.
This lens has a large focal length which produces a close image with a small field of view and minimal distortion.
In these sample images, the sensor used was a 1/4" Sony ICX618. The first image is focused at a distance of 53mm from the lens and the second at 65mm. This lens has a small F Number of f2.8 creating a narrow depth of field.
