Scorpion Vision

M12 Lens 1.08mm F2.0



Shipping & Returns


Free shipping to all UK addresses (subject to a minimum order value of £20).

Standard shipping to all other destinations - select destination on checkout to get pricing.


If you would like to return or have any questions about your returning your item, please contact

Key Features

  • Focal Length: 1.08mm
  • F Number: F2.0
  • Iris: Non Adjustable
  • Mount: M12
  • Format: 1/3"
  • Filter Size: n/a
  • Megapixel: 5MP
  • Horizontal Field of View: 185 Degrees
  • Distortion: <-93%
  • Back Focus: 3.76mm
  • Wavelength: 400nm - 900nm


Sample Images

Sensor: 1/2.8 inch Sony CMOS sensor IMX236LQJ

In the images below, the screw measures 26mm in length and 12mm in diameter at the screw head

Minimum object distance: 1mmdfk-afux236-m12-svl-ir01020b5m-1mm.jpg

Object distance: 2mmdfk-afux236-m12-svl-ir01020b5m-2mm.jpg

Object distance: 4mmdfk-afux236-m12-svl-ir01020b5m-4mm.jpg
